Barco C‑series SMPS Low‑Voltage Power Board

1. AC‑DC Multi‑rail Low‑Voltage Power Conversion Converts facility AC mains into regulated DC outputs including +3.3 V, +5 V, +12 V and other auxiliary voltages. It provides stable operating power for cinema controller board, fan controller board, ICMP media module, cooling fans, sensors, shutter drive and internal communication circuits. The lamp high‑voltage ignition power is handled independently by the LPS unit, not by this SMPS board.More products: www.plcva.com
2. Power‑good Signal & System Startup Sequencing Generates power‑good status signals. It implements controlled power‑on sequence for each internal circuit board to avoid hardware damage caused by disordered voltage rise during projector boot‑up. Stand‑by power remains available even when the projector is in sleep state for network remote wake‑up function.
3. Built‑in Multi‑layer Hardware Protection Integrates over‑current protection, over‑voltage protection, short‑circuit protection and over‑temperature protection. When fault conditions occur, it will shut down output rails automatically to prevent secondary damage to downstream circuit boards. Fault status signals are sent to the fan controller board and main cinema controller board for alarm logging.
4. Voltage Status Feedback & Diagnostics Continuously monitors its own output voltage rails. It reports power‑supply health status via internal backplane bus. Operating status and fault codes can be read with Barco Communicator service software for on‑site troubleshooting.
5. Hot‑swappable Plug‑in Structure Installed in the projector power compartment as a drawer‑type module. It can be replaced during maintenance procedures following official service steps. It is equipped with built‑in cooling fan for self‑dissipation to adapt long‑time continuous running inside cinema projection booths.

Barco C‑series SMPS Low‑Voltage Power Board

2. Applications

1. Original & Replacement Spare for Barco C‑series Digital Cinema Projectors Core low‑voltage power spare for DP2K‑12C, DP2K‑20C, DP2K‑25C digital cinema projectors. It solves typical failures such as no boot, random reboot, no fan rotation and logic board power‑loss caused by SMPS hardware failure.
2. Power Infrastructure for DCI‑compliant Cinema Projection System Supplies stable low‑voltage power for all control, media processing and thermal‑management electronics during commercial long‑hour movie screening. It ensures continuous and stable operation of projection equipment inside movie auditoriums.

Barco C‑series SMPS Low‑Voltage Power Board

1. Cinema‑site Equipment Maintenance & Retrofit Projects Used for on‑site repair of existing C‑series projection systems. Only the defective SMPS module needs to be swapped, without replacing lamp power supply, optical engine or other functional assemblies, minimizing cinema downtime.
2. Critical Spare‑part Inventory for Cinema‑chain Maintenance Teams Stored as key spare component by cinema technical departments. It is used for emergency replacement to avoid screening interruption caused by power‑board sudden failure.

Barco C‑series SMPS Low‑Voltage Power Board

Barco C‑series SMPS Low‑Voltage Power Board

Understand the lowest price, please contact via email: plcvarious@foxmail.com

More products: www.plcva.com

Many products are not yet on the shelves please contact us for more products.
