Schneider Electric TeSys‑D 3‑Pole AC Contactor, Model LC1D65

Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mailbox：plcvarious@foxmail.com

+086 18205988494

Introduction

Core Functions

Electromagnetic Power Switching It adopts electromagnetic coil driving mechanism. When the control coil is energized, the main contacts close to switch‑on 3‑phase 380V AC power circuit; when de‑energized, main contacts open to cut‑off power supply. Thermal conventional current reaches 80A, AC‑3 motor‑load rated operational current is 65A, applicable for 30‑kW three‑phase motor at 380V‑400V.More products: www.plcva.com
Built‑in Auxiliary Contacts (1NO + 1NC) Integrated 1 normally‑open and 1 normally‑closed auxiliary contacts. These mirror contacts are used for interlock‑logic, status feedback, signal‑transmission to PLC/HMI, interlocking forward‑reverse motor circuits, and indicator‑lamp control within control loops.

Schneider Electric TeSys‑D 3‑Pole AC Contactor, Model LC1D65

High‑capacity Load Switching Capability Supports multiple utilization categories: AC‑3 for squirrel‑cage motor start‑stop, AC‑1 for resistive loads, AC‑4 for frequent plugging‑reversing motor‑switching. It can withstand large starting inrush current of motors, with rated making‑breaking capacity up to 1000A at 440V, ensuring reliable switching under motor‑starting transient‑current
Flexible Installation & Reliable Wiring Support DIN‑rail mounting or direct‑screw panel mounting. Power circuit adopts EverLink BTR screw‑type terminals, suitable for solid/flexible cables with wide cross‑section range, anti‑loosening and high‑reliability wiring performance. Front‑face IP20 protection degree prevents accidental‑touch of live parts
Industrial‑grade Durability & Compatibility Mechanical durability up to 6 million cycles, maximum operating frequency 3600 cycles per hour. It can be matched with thermal‑overload relays (LRD series) to compose complete motor‑starter sets for overload‑protection. Complies with IEC 60947‑4‑1, UL, CCC, CE, EAC international standards, adapts to‑40℃ ~ +60℃ industrial‑site ambient‑temperature.
Expandable Function Design Allow external attachment of auxiliary‑contact modules, surge‑suppression modules, mechanical‑interlock accessories to realize forward‑reverse interlock, more auxiliary‑signal points and coil‑surge‑absorption functions. Multiple coil‑voltage options (AC/DC) are selectable for different control‑system requirements.More products: plcva.com

Schneider Electric TeSys‑D 3‑Pole AC Contactor, Model LC1D65

Applications & Purposes

LC1D65 is a mainstream industrial electromagnetic contactor widely used in low‑voltage electrical control cabinets, for automatic switching of motors and AC power loads.

Typical Industries ‑ Mechanical manufacturing: machine‑tool equipment, conveyor‑lines, material‑handling systems ‑ HVAC & water‑treatment: water‑pumps, fans, air‑compressors, water‑treatment‑plant equipment ‑ Food & beverage, packaging‑automation production‑lines ‑ Building electrical‑systems, power‑distribution cabinet‑control loops ‑ Metallurgy, cement, chemical‑industry auxiliary‑motor control

Schneider Electric TeSys‑D 3‑Pole AC Contactor, Model LC1D65

Main Purposes

Realize remote automatic start‑stop control for three‑phase asynchronous motors (max. 30 kW @380V AC‑3), controlled by PLC, relay or button‑control‑circuits.
Switch on‑off large‑current resistive‑loads such as heating‑tubes, heaters, lighting‑groups.
Cooperate with thermal‑overload relays to build motor‑starter units, implementing motor running‑control plus overload‑protection.
Construct forward‑reverse motor‑control circuits with mechanical‑interlock accessories, to realize positive‑negative rotation of equipment.
Provide equipment‑running‑status feedback signals via built‑in auxiliary contacts for upper‑level control‑system and indicator‑lamp display.
Applied in low‑voltage control cabinets as core power‑switching component for automated‑production‑process.
