Main Functions

CAN‑bus communication interface: Connects to AGC242 main controller via CAN‑bus, receives regulation commands and load‑sharing signals from AGC242, realizes digital‑to‑analog signal conversion.More products: www.plcva.com
Governor analog drive output: Provides configurable analog output signals (voltage / current) to drive external diesel engine speed governor, executes speed rise/fall adjustment commands sent by AGC242 controller.

DEIF IOM230 CAN‑bus Analogue Output Interface Module

AVR excitation regulation output: Delivers analog control signals to Automatic Voltage Regulator (AVR), completes generator output voltage fine‑tuning.
Analog P/Q load‑sharing output: Unique feature of IOM230, provides active power (P) and reactive power (Q) analog load‑sharing signals for parallel gensets, supports analog‑mode load balancing among multiple generator sets besides CANshare digital load‑sharing of AGC242.
Signal configuration via DIP‑switches: On‑board DIP switches and potentiometers adjust output signal types (0‑20 mA, ±12 VDC etc.), signal range and offset calibration, adapt to different governor and AVR hardware specifications.
Module diagnosis & status feedback: Transmits module operating status, output channel fault and communication fault information back to AGC242; fault alarms can be displayed on controller HMI.
Industrial isolation & anti‑interference: Galvanic isolation between CAN‑bus control side and field analog output side, suppresses electromagnetic interference in marine and industrial power‑house environments.
Wide‑range power supply: Operates on 12 VDC / 24 VDC power supply, fits standard genset control cabinet power architecture。

DEIF IOM230 CAN‑bus Analogue Output Interface Module

Multi‑generator parallel power plant system: Used together with AGC242 controller for diesel generator parallel operation; implements engine speed control, generator voltage adjustment and analog active/reactive power load sharing among multiple gensets。
Marine power management system: Deployed on vessel main power stations, supports island‑mode parallel running of shipboard diesel generators, stabilizes bus frequency and voltage, distributes active & reactive load evenly among gensets.

DEIF IOM230 CAN‑bus Analogue Output Interface Module

Industrial standby power station: Applied for factory critical backup power plants, data‑center standby generators, oil‑onshore facilities; expands analog regulation capacity for AGC242 when matching non‑digital‑interface governor and AVR units.
Retrofit & spare‑part replacement: For upgrading old genset control systems; replaces ageing IOM230 modules in existing AGC242 parallel‑gen‑set installations to restore analog governor / AVR and analog load‑sharing functions.plcva.com
Hybrid digital‑analog parallel system: Adopts CAN‑bus digital communication between AGC242 and IOM230, while retaining traditional analog signal wiring for governor / AVR; compatible with legacy mechanical governors and analogue‑type voltage regulators which lack CAN‑bus interface.
