Omron CP1H‑X40DT‑D‑SC, CP1H‑Series Compact Programmable Logic Controller

Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mailbox：plcvarious@foxmail.com

+086 18205988494

Introduction

Main Functions

Integrated Digital I/O Control Built‑in total 40‑point I/O: 24‑point DC24V digital inputs (compatible with NPN/PNP sensors), 16‑point NPN sinking transistor outputs (0.3 A per channel). Power supply: DC 20.4‑26.4 VDC. Program memory: 20 K steps; data memory: 32 K words. Basic instruction execution speed: 0.1 μs. Supports ladder diagram, structured text (ST), function‑block programming via CX‑Programmer software.plcva.com
4‑Axis High‑speed Positioning Control Equipped with 4‑channel high‑speed counter inputs (max 100 kHz), and 4‑channel pulse‑train outputs (max 100 kHz). It can directly drive stepper drives and servo drives for multi‑axis point‑to‑point positioning, speed control and origin return without extra positioning modules. Supports linear interpolation, target‑value interrupt and range‑comparison interrupt functions.
Rich Interrupt & Quick‑response Functions 8 built‑in interrupt input points, scheduled interrupt function. Captures short‑pulse field signals, responds to urgent field events in real‑time. Contains one built‑in analog setting input (0‑10 VDC) for on‑site parameter adjustment without modifying PLC program.
Flexible Expansion Capacity Supports up to 7 expansion units. Combine CP1W I/O modules and partial CJ1 special‑function units, maximum total system I/O reaches 320 points. Realizes digital‑I/O expansion, analog processing and field‑bus access. Built‑in backup battery preserves data memory and real‑time clock calendar information during power‑off events.
Multi‑port Communication Capability Standard USB port for programming and monitoring. The‑SC variant integrates RS‑232C serial port onboard. Supports Modbus‑RTU master/slave, Host‑Link, NT‑Link protocols. Additional option boards can add RS‑422/485 or Ethernet interfaces to connect HMI, inverters, sensors and upper‑level host computers.
Diagnostic & Maintenance Features 2‑digit seven‑segment status display for error code indication. Built‑in system error log, power‑off detection, and battery‑low alarm functions. Supports program upload/download, online monitoring and forced‑I/O operation for convenient commissioning and troubleshooting. Complies with CE, UL industrial standards.

Omron CP1H‑X40DT‑D‑SC

Applications / Purposes

Mid‑small‑size automated machinery control Serves as main controller for standalone automation equipment, including packaging machines, labeling machines, filling equipment, assembly machines, test jigs and special‑purpose machines. Executes sequence logic and multi‑axis motion positioning for servo/stepper systems.plcva.com
Conveyor and material‑handling systems Controls conveyor lines, sorting mechanisms, lifting stations and material transfer equipment. Processes sensor signals and performs high‑speed pulse positioning for material positioning and sorting workflows.
Retrofit & upgrade for existing automation equipment Replaces legacy compact PLC systems. Its native RS‑232C port (‑SC version) facilitates direct connection with old‑generation serial HMIs and field devices without extra adapter boards.
Compact factory‑cell control solutions Deployed inside small control cabinets where space is limited. Handles local machine logic, motion control and serial data exchange. Can link to upper‑level field‑bus networks via optional communication units to connect with factory‑wide control systems.
