Danfoss PVEH-U Electrical Actuator
- Warranty： 365 days
- Quality: Original module
- Condition： New / Used
- Warehouse: Spot
- Delivery time: Shipped in 3 days after payment
- Mailbox：plcvarious@foxmail.com
Introduction
Old Part No.: 157B4044 | New Replacement Code: 11166821
Main Functions
- Proportional Hydraulic Valve Drive Control Receive 0–10V analog control signal from PLC or machine controller, convert the electrical command into mechanical spool displacement of PVG proportional valve. Continuously regulate hydraulic flow and direction proportionally.
- Wide DC Power Supply Working voltage range 11–32 VDC, compatible with 12V / 24V mobile machine battery power systems.More products: www.plcva.com
- Active Fault Diagnosis & Monitoring Active type built-in fault detection circuit. It monitors actuator coil, wiring and internal hardware status in real time, outputs fault feedback signal to host controller once failure occurs.
- AMP 4-pin Electrical Connection & IP66 Protection Equipped with 4-pin AMP connector. IP66 enclosure rating, dust-proof and splash-proof, suitable for harsh outdoor mobile machinery environment.
- High-precision Closed-loop Position Control Internal position sensor forms closed-loop feedback for valve spool, ensures repeatable, accurate proportional response, reduces hysteresis for smooth hydraulic movement.
- Modular Installation Directly mounted onto PVG32 and PVG100 hydraulic valve modules, easy replacement and maintenance.
New Replacement Code: 11166821
Applications / Purpose
This PVEH-U proportional electric actuator is the control core for Danfoss PVG load-sensing proportional valve banks, widely used on mobile hydraulic machinery.
- Construction machinery: Excavators, loaders, telescopic handlers, road rollers, pavers.
- Agricultural machinery: Tractors, harvesters, sprayers.
- Material handling: Forklifts, container handlers, aerial work platforms.
- Special mobile equipment: Waste trucks, forestry machines, offshore auxiliary hydraulic units. It controls boom lifting, arm movement, steering, travel speed and other hydraulic functions, to achieve stepless smooth speed regulation and precise motion control for mobile hydraulic systems.
