SCHNEIDER

SCHNEIDER 140CRA93200 MODICON Module

Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mailbox：plcvarious@foxmail.com

+086 18205988494

Introduction

Function of SCHNEIDER 140CRA93200 MODICON Module

The 140CRA93200 is a dual-channel RIO (Remote Input/Output) drop adapter module belonging to Schneider Modicon Quantum PLC series, mounted on the backplane of remote I/O sub-stations and communicating via coaxial RIO bus cable.

Core Functions:

It works in pair with the 140CRP93200 RIO master adapter on the CPU local rack, establishing high-speed bidirectional data transmission between the main CPU rack and remote I/O sub-stations through coaxial cables.
It transmits all input/output data of digital and analog modules at remote sites, enabling the CPU to read signals from field sensors and send control commands to valves, motors and other actuators far away.
One single module supports up to 27 expansion I/O modules, greatly expanding the total I/O capacity of the PLC system and solving the problem of scattered field equipment and long wiring distances.
The dual-channel hardware design supports redundant communication links to enhance transmission reliability for critical processes such as chemical, power and water treatment industries, with built-in circuit fault detection and disconnection alarm functions.
Hot-swap compatible, allowing module replacement without system shutdown, ideal for continuous-operation industrial production lines and process control systems.

Typical Applications

Petrochemical plants, power stations, metallurgy factories, water treatment facilities, tunnels and large automated production lines that require long-distance distributed I/O control.
