A-B Allen-Bradley

Model: 1756-ENBTA

Full Name: ControlNet Communication Module

Brand: Allen‑Bradley (Rockwell Automation)

Compatible Platform: ControlLogix 5500 PLC Chassis

The 1756-ENBTA is a dedicated ControlNet fieldbus gateway module designed for ControlLogix modular PLC systems. Its key functions are detailed as follows:

1. Dedicated Gateway for ControlNet Deterministic Fieldbus Mounted on the ControlLogix backplane, this module acts as an exclusive data exchange gateway between the Logix CPU and ControlNet industrial fieldbus. ControlNet is a Rockwell deterministic bus optimized for high-real-time motion and process control, featuring fixed transmission latency and negligible jitter for high-precision synchronized I/O and multi-axis drive signals.
2. Dual-Media Redundant Ports for Enhanced Bus Reliability It is equipped with two independent communication ports supporting two transmission media:

• Coaxial cable port: For short-distance workshop wiring with 5 Mbps transfer speed;
• Fiber optic port: For long-distance runs or sites with heavy electromagnetic interference (near welding machines and high-power motors) to isolate high-voltage noise. Dual-link redundant networking is supported. Communication automatically switches to the backup channel if one cable fails, eliminating production line downtime caused by single cable damage.

3. Real-Time I/O Scanning & Synchronized Motion Control The module executes periodic real-time data exchange with remote digital/analog I/O blocks, servo drives and variable frequency devices on the ControlNet bus to ensure synchronized operation of multiple field equipment. It supports high-precision synchronous processes such as synchronized roller conveyors, multi-robot coordination and continuous chemical process control for hard real-time automation requirements.
4. Cross-Network Data Routing Between Hierarchical Networks

• Lower layer: Connect all field devices on the ControlNet bus;
• Upper layer: Exchange data with the CPU via backplane, and cooperate with 1756-EN2T Ethernet modules to forward fieldbus data to HMIs, SCADA and MES upper-level systems. It realizes seamless communication between the ControlNet device control layer and Ethernet information layer, balancing high-speed field control and factory-wide data collection.

5. Comprehensive Bus Diagnostics & Fault Alarm Function Front panel LEDs indicate module running status, bus link state and fault alerts. The CPU can retrieve detailed diagnostic codes including short circuits, cable breaks, lost nodes, communication overload and media link errors. PLC logic can trigger audible/visual alarms based on fault codes to accelerate on-site troubleshooting.
6. Multi-Module Expansion for Bus Load Segmentation Multiple 1756-ENBTA modules can be installed on one ControlLogix chassis. Each module drives an independent ControlNet bus segment to distribute network load, avoiding communication delay caused by excessive nodes on a single bus. This design fits large-scale facilities such as automotive assembly plants and chemical processing plants with dozens of field stations.
7. Rugged Industrial Design with Hazardous Location Certifications Powered by standard 24VDC chassis backplane supply, it features a wide operating temperature range. UL and CE certifications allow deployment in Class I Division 2 hazardous locations, suitable for metallurgy, oil & gas, water treatment, heavy machinery and other harsh industrial applications.
