TRICONEX

1.Term Explanation

1. Triconex: Brand owned by Schneider Electric, delivering Tricon Triple Modular Redundant (TMR) SIS Safety Instrumented Systems for ESD, F&G, BMS furnace safety and HIPPS high-pressure protection in oil & gas, chemical, coal chemical and power industries.
2. EMP II: Abbreviation of Enhanced Multi-Processor Generation 2, the second-generation high-end main processor platform of Tricon series.
3. MP3007: New upgraded hardware model, successor iteration of MP3006, flagship processor card designed for Tricon V10 systems.
4. Processor Module: The core unit of the whole SIS system, responsible for logic calculation, IO scheduling and backplane bus management.
5. Enhanced CPU: Upgraded central processing unit, featuring optimized computing core, expanded high-speed SRAM, faster logic scan rate, higher maximum IO point capacity and stronger concurrent communication cache compared with MP3005 and MP3006.

Supplementary Core Architecture Note:

Adopts native TMR triple 2-out-of-3 fault-tolerant architecture. Three MP3007 modules must operate synchronously within one rack. Three independent CPU cores execute identical safety logic in parallel and cross-verify calculation results every scan cycle. Failure of any single processor, memory or TriBus bus will not trigger spurious trip or fail-to-trip, fully certified TÜV SIL3.

Key hardware upgrades versus MP3005/MP3006:

• Larger onboard SRAM for massive real-time process caching and extended long-duration SOE event storage;
• Faster logic scan speed without delay for complex interlocks and multi-sequence timing logic;
• Higher ceiling of maximum IO points supported per rack, applicable to super-large integrated refineries;
• Optimized TriBus triple backplane bus controller with greatly improved concurrent scheduling capacity for local IO and SRXM fiber remote IO;
• Strengthened communication cache to support dozens of upper HMI, OPC and MES clients simultaneously when matched with NCM4329 network modules. Independent flash partitions store safety logic with hardware-level program integrity check after power-on to prevent tampering or corruption. Full-series compatibility: Supports 3700-series AI analog input, SDO digital output, DI digital input, HCU FTA terminal assemblies, SRXM4210 fiber remote extenders and NCM4329 Ethernet communication modules. Fully compatible with Tricon V10 and backward compatible with V9.6 platform. Online hot-swap and bumpless redundant switchover are supported; safety interlock operation remains uninterrupted during replacement of a single faulty card.

2. Core Main Purposes

1. Complex safety interlock logic calculation for super-large process plants (Core Function) Executes full-process safety programs downloaded via TriStation, including plant-wide ESD emergency shutdown, F&G flammable/toxic gas leakage protection, pipeline HIPPS overpressure cut-off, boiler BMS furnace ignition/fuel trip, and TS3000 anti-surge protection for large compressor units with complex multi-branch interlock logic. Three MP3007 modules perform independent parallel calculation, and hardware 2oo3 voting outputs trip commands to drive SDO output cards for valve cut-off and unit shutdown.
2. Periodic data acquisition and full-range fault diagnosis for local & remote IO Cyclically collects analog and digital signals from local rack DI/AI cards; reads instrument signals from remote explosion-proof IO cabinets over SRXM4210 fiber extenders; real-time diagnoses loop short circuits, open circuits, transmitter faults, offline cards and fiber communication attenuation. All faults generate SOE sequence events with millisecond timestamps. The large memory cache tens of thousands of real-time process points without alarm record loss during prolonged network disconnection.
3. Triple TriBus bus synchronization and hardware fault-tolerant voting Three MP3007 modules synchronize programs, high-precision clocks and full-point process data in real time through triple redundant backplane bus. Calculation results from three channels are cross-checked each scan cycle. If single-channel core, memory or bus communication malfunctions, the other two channels continuously output reliable interlock instructions to eliminate all single-point failure risks.
4. High-precision global clock synchronization to guarantee SOE audit accuracy plant-wide Built-in high-precision hardware clock; clocks of three processors are synchronized within milliseconds. Local cabinets and cross-site fiber remote IO share a unified time reference with zero timestamp deviation for interlock trips, instrument faults and process alarms, fully meeting mandatory compliance and accident traceability requirements of national safety supervision and petrochemical industry standards.
5. Coordinate NCM4329 communication modules to support large-scale concurrent data exchange with upper systems Uniformly schedules NCM Ethernet communication cards to connect plant-wide DCS, multiple HMI workstations, OPC servers, real-time databases and MES production scheduling systems. The large built-in cache offloads communication load to avoid stuttering when dozens of clients access concurrently, without occupying computing resources for interlock logic scan to guarantee fixed-cycle safety operation.
6. Safety logic storage, verification, bumpless online modification and batch program download Non-volatile onboard flash memory solidifies safety logic and automatically executes hardware integrity check upon power-on to prevent logic tampering. Supports partial online logic modification, incremental program download and synchronous batch program distribution across multiple racks without full plant shutdown, convenient for technical renovation and logic optimization debugging of large refineries during continuous production.
7. Centralized management of fiber remote IO clusters Simultaneously manages multiple sets of SRXM4210 fiber remote extension cabinets covering scattered tank farms, pipe rack valve chambers, terminal loading areas and remote instrument zones on offshore platforms. Fiber electrical isolation eliminates ground loops and lightning electromagnetic interference; remote IO maintains identical SIL3 safety level as local rack equipment.
8. Redundant online maintenance for uninterrupted safe production A single faulty MP3007 can be hot-swapped directly online, while the remaining two processors fully undertake all safety calculation tasks. Million-ton refineries, LNG plants and power stations avoid huge economic losses from full plant shutdown during maintenance.

3. Applicable Application Scenarios

Scenario 1: Million-ton integrated refinery & ethylene super-large plants (Core Application)

Large comprehensive refineries, PX, ethylene, aromatics and hydrocracking facilities with tens of thousands of IO points and multi-unit linkage ESD systems. The MP3007’s expanded memory and high-speed scan capacity support plant-wide integrated safety interlock and mass storage of SOE alarm events.

Scenario 2: Large LNG liquefaction plants, receiving terminals and offshore oil & gas platforms

HIPPS high-pressure protection for LNG storage tanks, gasification units and terminal loading systems; plant-wide F&G gas monitoring systems on offshore platforms with multiple fiber remote IO cabinets covering scattered well zones and flare valve groups. MP3007 centrally coordinates long-distance instrument data acquisition across separated areas.

Scenario 3: Large coal chemical, coal-to-olefin and ammonia integrated high-temperature & high-pressure plants

High-risk sections including gasifiers, shift reactors and synthesis towers with multi-workshop linkage interlocks and complex timing process protection. The high-capacity cache supports acquisition and diagnosis of thousands of HART smart analog instrument loops across the whole plant.

Scenario 4: BMS furnace safety systems for large thermal power & combined cycle gas power plants

Furnace safety supervision for multiple boilers and turbine units, supporting concurrent data exchange with plant DCS, scheduling centers and remote centralized control rooms. MP3007 ensures delay-free calculation of furnace fuel cut-off and ignition interlocks.

Scenario 5: Full-line HIPPS protection systems for long-distance oil & gas trunk pipelines

Clusters of distribution stations and block valve chambers deployed along cross-regional long-distance pipelines with widely distributed SRXM fiber remote IO. One MP3007 rack centrally coordinates full-line pressure, leakage monitoring and emergency overpressure cut-off interlocks.

Scenario 6: TS3000 cluster protection for large air separation and centrifugal compressor units

Multiple large air compressors, syngas compressors and refrigeration compressor units in chemical parks with linkage anti-surge, overspeed and lube oil shutdown protection. Complex dynamic logic relies on MP3007 enhanced high-speed CPU for real-time operation.

Scenario 7: Overseas EPC export mega oil & gas, chemical and power plant projects

Internationally recognized TÜV SIL3 safety certification, ultra-large IO capacity compatible with overseas integrated giant factories, standardized universal spare parts, and compatibility with global mainstream HART transmitters and DCS control systems, facilitating centralized on-site maintenance and remote online debugging for overseas projects.

4. Supplementary Key Hardware & Safety Features

1. Safety Certifications: TÜV Rheinland IEC61508 SIL3, IEC61511 process safety standard, UL/CE industrial explosion-proof and EMC electromagnetic compatibility certifications;
2. Architecture Spec: Standard TMR triple redundant 2-out-of-3 fault tolerance; three MP3007 modules must run synchronously in one rack;
3. Core Upgrade: Enhanced CPU with improved computing speed, expanded SRAM memory and higher maximum supported IO points, superior to MP3006/MP3005/MP3101S2;
4. Storage Configuration: Large high-speed SRAM caches real-time process data and SOE events; independent Flash memory solidifies safety programs, with cached data retained briefly after power loss;
5. Bus Compatibility: New-generation optimized TriBus triple backplane bus, compatible with full series AI/DI/SDO IO cards, 3703E HART FTA terminal boards, SRXM4210 fiber remote modules and NCM4329 communication cards;
6. Timing Performance: High-precision hardware synchronized clock, zero millisecond offset for SOE event timestamps to meet safety supervision audit requirements;
7. Environmental Performance: Industrial wide-temperature hardware with strong EMI/RFI anti-interference, adapting to harsh coastal, chemical high-temperature and dusty working conditions;
8. Maintenance Advantages: Standard slot for large Tricon racks, supporting online hot-swap, incremental online logic download and remote program debugging; spare part replacement requires no plant shutdown.
