BENTLY NEVADA

1. Bently Nevada: A world-renowned manufacturer of turbomachinery condition monitoring and safety protection systems
2. 3500/53: Model designation of electronic overspeed monitor card for the 3500 rack system
3. 133388-01: Original factory spare part number for this overspeed detection module hardware
4. Electronic: Adopts digital electronic logic, different from mechanical overspeed trip equipment
5. Overspeed Detection Module: Specialized card for real-time rotational speed monitoring and overspeed protection judgment

2. Core Product Functions

1. Triple Redundant Independent Speed Acquisition Equipped with three independent speed measurement channels, it synchronously receives pulse signals from magnetoelectric or Hall-effect keyphasor transducers. The three groups of speed data are mutually compared to realize triple modular redundancy and fault tolerance, preventing protection failure caused by single-channel damage.
2. Electronic Overspeed Logic Judgment Built with high-precision speed calculation circuits to compute the actual rotor rotational speed in real time. Multi-stage overspeed thresholds (warning and trip limit) can be configured; protection actions will be triggered instantly once the rotational speed exceeds preset limits.
3. Unit Safety Interlock Output It is equipped with passive hard relay contact outputs. When overspeed occurs, trip interlock signals are directly sent to unit trip solenoid valves. This protection loop operates independently of DCS and PLC, and can execute overspeed trip even under power failure or communication breakdown of upper control systems.
4. Channel Self-test & Fault Diagnosis It continuously self-checks sensor wire breakage, signal loss and internal hardware faults. Fault alarms will be triggered upon abnormalities to remind maintenance in advance and avoid failure of overspeed protection.
5. Full 3500 System Coordination It uploads rotational speed values, overspeed alarms and channel fault data to the 3500 rack controller for real-time display and local data logging, and transmits related status information to plant DCS for long-term condition recording.

3. Industrial Applications

1. Compatible System Exclusively designed for Bently Nevada 3500 series monitoring and protection racks, compatible with 3500/50 keyphasor cards, all types of keyphasor transducers and intrinsically safe barriers.
2. Applicable Rotary Equipment Turbo-generators, gas turbines, large steam turbines, process compressors and heavy-duty refinery turbomachinery; overspeed of such equipment may lead to catastrophic rotor fracture and permanent equipment damage.
3. Key Application Purposes

• Monitor real-time rotor speed via triple redundant channels, serving as the highest-level safety protection for rotating units;
• Output independent hard-contact trip signals to force unit shutdown when overspeed threshold is reached, avoiding severe runaway accidents;
• Support two-tier alarms including overspeed pre-warning and critical trip alarm to remind operators to reduce load speed in advance;
• Continuously diagnose probe wire breakage, line short circuit and module hardware faults to eliminate blind spots in safety protection;
• Adopt an independent hardware protection loop that will not be invalidated by control system crash or communication interruption to maximize protection reliability;
• Record time-series overspeed fault data for post-failure traceability and root cause analysis.

4. Applicable Industries & Scenarios Thermal power plants, combined-cycle gas power stations, petroleum refineries, coal chemical plants, large chemical facilities and metallurgical power workshops equipped with high-power turbomachinery.
