BENTLY NEVADA

Term Explanation

1. Bently Nevada: Professional global supplier of turbomachinery condition monitoring and protection systems
2. 125768-01: Original factory spare part number of the rack interface module hardware
3. Rack Interface: Central gateway interface for internal backplane bus communication of the 3500 rack
4. I/O Module: Input/output card with digital signal transmission and alarm relay contact functions
5. 3500/20: Dedicated rack communication interface card model for the 3500 monitoring system

2. Core Product Functions

1. Centralized Collection and Forwarding of Rack Bus Data Serving as the main interface of the 3500 rack backplane bus, it uniformly collects monitoring data, alarm status and fault codes from all functional cards inside the rack including 3500/40 vibration cards, 3500/50 keyphasor cards and 3500/53 overspeed cards, then packages and transmits data to external systems.
2. Multi-protocol Communication with Upper Control Systems It supports multiple standard industrial communication protocols to realize two-way data exchange with DCS, PLC, industrial host computers and SCADA systems. It uploads real-time operating data such as unit vibration, rotational speed, temperature and overspeed, and receives parameter configuration commands issued by upper systems.
3. Digital Alarm Input & Output (I/O Capability) Equipped with multiple passive relay contact outputs, it sends hard-wired contact signals to drive audible and visual alarms and auxiliary interlock loops when faults such as excessive vibration, overspeed or module failure occur. It also receives digital status signals from external equipment and transmits them to the rack for logical judgment.
4. Rack-wide Parameter Configuration and Storage All alarm thresholds, unit operating parameters and protection logic of every module in the rack are configured and downloaded through the 3500/20 module. Configuration parameters are stored locally and retained after power failure.
5. Centralized Diagnosis and Reporting of Rack Hardware Faults It continuously diagnoses faults of rack power supply, all internal function cards and sensor circuits, summarizes all diagnostic data and uploads them to upper monitoring screens to display the overall health status of the rack for convenient maintenance troubleshooting.

3. Industrial Applications

1. Compatible Matching System Mandatory basic communication card for the complete Bently Nevada 3500 series turbomachinery protection and monitoring rack system.
2. Applicable Rotary Equipment Turbo-generators, gas turbines, large process compressors, air blowers, steam turbines and heavy-duty rotary turbomachinery for refineries and chemical plants.
3. Key Application Purposes

• Collect vibration, speed and overspeed data from all internal rack modules uniformly, and build data transmission channels between the 3500 rack and central control DCS/PLC;
• Output independent hard-contact alarm signals to trigger on-site audible & visual alarms and auxiliary interlock reminders;
• Complete parameter setting, logic tuning and local data storage for all monitoring cards in the whole rack;
• Collect hardware and sensor fault information of the entire rack in a centralized manner to realize unified equipment diagnosis and management;
• Matched with isolation barriers for signal transmission in explosion hazardous areas of power and chemical plants.

4. Applicable Industries & Scenarios Thermal power plants, combined-cycle gas power stations, petroleum refineries, coal chemical plants, oil & gas long-distance compressor stations and metallurgical power workshops equipped with large turbomachinery.
