Rosemount 3051L Series WirelessHART Flange‑Mounted Differential‑Pressure Level Transmitter
- Warranty： 365 days
- Quality: Original module
- Condition： New / Used
- Warehouse: Spot
- Delivery time: Shipped in 3 days after payment
- Mailbox：plcvarious@foxmail.com
Introduction
Brand
Rosemount (USA, owned by Emerson Group). World‑renowned manufacturer of pressure, differential‑pressure and level transmitters for process industriesEmerson.
Rosemount 3051L Series WirelessHART Flange‑Mounted Differential‑Pressure Level Transmitter
Full Product Name
Rosemount 3051L Series WirelessHART Flange‑Mounted Differential‑Pressure Level Transmitter
3051L: Flange‑type level transmitter main body. Wireless version adopts WirelessHART protocol, powered by smart battery module without signal wiring. Can be assembled with 1199 diaphragm seal system for tank differential‑pressure level measurementEmerson.www.plcva.com
Rosemount 3051L Series WirelessHART Flange‑Mounted Differential‑Pressure Level Transmitter
Main Functions
- Differential‑pressure level measurement principle: Calculates liquid level height from hydrostatic differential pressure generated by liquid column. Supports direct level reading and tank volume calculation. Turn‑down ratio up to 150:1, reference accuracy up to ±0.075% of span.
- WirelessHART communication: No field wiring required. Data reliability >99%. Smart power module provides up to 10‑year service life and is field‑replaceable. Built‑in antenna, maximum wireless range 225 m. User‑selectable update interval from 1 second to 60 minutesEmerson.
- Bluetooth BLE local commissioning: Parameter configuration and fault diagnosis via mobile devices without physical wiring. Optional graphic back‑lit LCD display for local readout of level, temperature and device status with multi‑language support.
- Advanced on‑board diagnostics: Loop integrity check, plugged impulse line detection, corrosion and housing moisture early warning to alert before process disruption and reduce unplanned downtime. SIL 2/3 functional‑safety certified for safety‑instrumented system applicationsEmerson.
- Direct mounting or optional Tuned‑System seal assembly reduces temperature drift and improves response time by over 80 % versus traditional capillary systems. Wetted‑part options: 316L stainless steel, Alloy C‑276, tantalum for corrosive fluids. Flange standards include ANSI, DIN, JIS etc罗斯蒙特中….
- Wide operating conditions: process temperature range ‑105 ℃ ~ 205 ℃, max working pressure 20.68 bar. Hazardous‑area approvals for explosive chemical environments罗斯蒙特中….
Rosemount 3051L Series WirelessHART Flange‑Mounted Differential‑Pressure Level Transmitter
Applications
- Tank level monitoring: Continuous liquid‑level measurement for storage tanks, buffer vessels and pressure vessels in chemical, refinery and oil‑gas industries. Inventory supervision for tank farms, ideal for widely‑spread measuring points where cabling is costly or impractical.
- Process vessel level control: Continuous level monitoring for reactors, separators and distillation columns, feeding data to DCS for monitoring and interlock alarming.
- Retrofit projects: Fast deployment of new measuring points without cable‑trench construction for sites with difficult cabling conditions.
- Level measurement for water‑treatment, coal‑chemical and power‑plant tanks, especially for corrosive media. Used for safety interlock, inventory metering and predictive maintenance.
Rosemount 3051L Series WirelessHART Flange‑Mounted Differential‑Pressure Level Transmitter
