Product Background

FAU810 is ABB’s modern‑generation intelligent flame‑analysis processor, belonging to the Uvisor™ flame‑scanner family, successor to older ABB Bailey flame‑detection products, part of ABB Symphony Plus combustion safety platform. It is a modular split‑design device: the FAU810 processing module plugs into the dedicated base. The base provides power input, field‑wiring terminals, DIP‑switch configuration, shared power / RS‑485 bus for multi‑unit networking, and DIN‑rail mounting. It is designed to work with ABB SF810 / DFS series flame detector probes. It is widely used for boiler combustion safety monitoring; it is also a common retrofit spare for old‑generation ABB flame‑monitoring systems.

ABB FAU810 Flame Analysis Unit

Main Functions

1. Dual‑channel independent signal processing: Accept input signals from two ABB flame detector probes; each channel runs separate analysis without mutual interference.
2. Flame signal analysis: Measure flame intensity, flicker frequency, signal quality, distinguish real burner flame from background radiation / reflected light to avoid false flame detection (“false‑fire” error).More products: www.plcva.com
3. Safety relay output: Independent SPDT relay contacts for flame‑on / flame‑off status and fault alarm; hard‑wired safety interlock for fuel‑cutoff protection when flame is lost.
4. Analog output: 2‑channel isolated 4‑20 mA analog output for flame intensity / quality data to DCS system.

ABB FAU810 Flame Analysis Unit

1. Redundant communication: Support redundant Profibus DP‑V1 and Modbus‑RTU for data exchange, remote configuration and diagnosis via Flame Explorer software.
2. Self‑diagnosis & fault monitoring: Continuous internal health check; report hardware, sensor, communication faults to control system.More products: www.plcva.com
3. Base‑side configuration: The base is equipped with DIP switches to select detector‑type for each channel; supports shared redundant 24 VDC power supply for multiple FAU810 units on same DIN‑rail.
4. Local operation: Built‑in LCD display and keypad on the module for on‑site parameter setting and real‑time status viewing.

ABB FAU810 Flame Analysis Unit

Applications & Usage

FAU810 (module + base) is the core control unit of ABB flame‑detection system, used together with SF810 / DFS flame‑scanner probes. Typical end‑use scenarios:

• Utility power‑plant boilers (coal‑fired, gas‑fired, oil‑fired boilers)
• Industrial boilers in petrochemical, metallurgy, cement, waste‑to‑energy plants
• Combustion safety interlock for burners: detect flame presence / loss, trigger fuel‑trip protection to prevent explosion risk
• Retrofit replacement for legacy ABB flame‑monitoring installations

ABB FAU810 Flame Analysis Unit
