Core Functions

Note: This is an auxiliary signal‑conditioning interface module for high‑voltage inverters. It does not generate high‑voltage power output; it processes feedback and interlock signals for the converter system.

1. High‑voltage side signal sampling & isolation conditioning Collects voltage and current feedback signals from medium‑voltage converter power‑cell circuits. Implements galvanic isolation, filtering and signal conditioning, converts high‑voltage measurement signals into low‑voltage level signals that can be recognized by the drive main‑control unit.
2. Cabinet‑level interlock signal processing Processes safety interlock signals from the inverter cabinet: door‑interlock, temperature‑overheat, cooling‑system status and other safety feedback signals. Conditions these discrete signals and sends them to main‑control board for safety‑protection logic judgment.
3. Fault‑signal transmission and status monitoring Transmits abnormal status signals of power‑cell, cooling system and cabinet auxiliary circuits to main‑control unit. Provides hardware‑level fault‑detection circuits for auxiliary circuit failure diagnosis.
4. Electrical isolation and noise suppression Provides galvanic isolation between high‑voltage power circuit side and low‑voltage control circuit side. Suppresses strong electromagnetic interference generated by high‑power converter, protects sensitive control electronics.
5. On‑board status indication On‑board LED indicators show power‑on and fault status for on‑site maintenance troubleshooting.

ABB UBC717AE01 Signal Conditioning & Interface PCB Module

Hardware Interfaces

• High‑voltage measurement signal terminals: Connect to converter power‑cell feedback circuits
• Interlock & status‑signal terminals: Connect to cabinet safety switches, temperature sensors and auxiliary relays
• 24 VDC power‑supply input terminals
• Signal output connectors: Connect to drive main‑control board
• Screw‑mount fixing for installation inside medium‑voltage inverter cabinet

ABB UBC717AE01 Signal Conditioning & Interface PCB Module

Main Applications & Deployment Sites

Core Application: Auxiliary signal‑conditioning interface PCB for ABB ACS1000 / ACS6000 medium‑voltage variable‑frequency drives, used for signal isolation, sampling and interlock processing of high‑power converter systems.More products: www.plcva.com

1. Thermal & Hydro Power Plants Auxiliary high‑power motors driven by ABB medium‑voltage drives: boiler feed‑water pumps, forced‑draft fans, induced‑draft fans, condensate pumps, large‑capacity cooling‑water pumps.
2. Mining Industry High‑voltage large‑power motor systems: mine hoists, belt conveyors, crushers, slurry‑pump drives equipped with ACS1000 / ACS6000 medium‑voltage drives.
3. Oil & Gas, Petrochemical & Refineries Large‑capacity compressors, pipeline pumps, heavy‑duty process‑motor drive systems.
4. Cement, Pulp & Paper, Metallurgy Heavy‑Industry Large‑scale kiln drives, mill motors, high‑power fan and pump systems.
5. Water‑supply & Waste‑water Treatment Plants Large‑scale water‑pumping‑station high‑voltage pump‑motor speed‑regulation systems.

ABB UBC717AE01 Signal Conditioning & Interface PCB Module

Key distinction summary for reference:

• UBC717AE01 (HIEE300927R0101): Medium‑voltage‑drive auxiliary signal‑conditioning interface PCB board.
• UFC911B101: ACS6000/ACS5000 medium‑voltage‑drive main‑control CPU board.
• KU C720 AE01: ACS1000 drive EPS power‑supply & signal‑conditioning PCB board.
• 216VC62a: Generator relay‑protection CPU board.
• UNITROL 1020: Generator excitation AVR regulator.
• CMA120: SYNPOL‑D marine basic controller‑HMI panel.
• CMA121: SYNPOL‑D rack power‑supply card.
• DSAI130A: DCS analog‑input I/O board.

Understand the lowest price, please contact via email: plcvarious@foxmail.com

More products: www.plcva.com

Many products are not yet on the shelves please contact us for more products.
