PP846A is a local/remote operator HMI. It receives real‑time process data from AC800M controllers, displays graphics, trends and alarms, and sends operator commands back to the DCS control systemABB Group.More products: www.plcva.com

1. Process visualization & graphical monitoring 10.4‑inch TFT‑LCD touch screen (800×600 SVGA). Displays process mimic diagrams, real‑time process variables (pressure, temperature, flow, level), motor/valve status, and equipment state. Supports vector‑based graphics, multi‑page navigation, and multi‑language displayABB Group.
2. Operator manual control & parameter setting Touch‑screen operation for start/stop commands, valve adjustment, set‑point modification, mode switching. Operator commands are transmitted to AC800M CPU controllers for execution.
3. Alarm management & event logging Real‑time alarm display, alarm history storage, alarm acknowledgement, and event log recording. Shows fault and abnormal process events for operator analysis and troubleshootingABB Group.
4. Trend curve & data logging Real‑time and historical trend charts for analog process parameters; supports data logging for process analysis and production tracing.
5. Multi‑protocol communication Dual‑port Ethernet for connection to System 800xA / AC 800M DCS controllers. Also equipped with RS‑232, USB interfaces. Project download, firmware update and data backup via USB or Ethernet. Configured by ABB Panel Builder engineering toolABB Group.
6. Rugged industrial hardware design Die‑cast aluminum housing, front‑panel IP65 protection rating, dust‑proof and splash‑proof. 24 VDC power supply, suitable for harsh industrial field environments.

ABB PP846A 3BSE042238R2 Panel

Hardware Interfaces

• 24 VDC power input
• Dual‑port 10/100 Ethernet ports for DCS communication
• RS‑232 serial port, USB ports for project download / data backup
• 10.4‑inch TFT touch screen, function keys
• Panel‑mount cut‑out installation for control cabinet

ABB PP846A 3BSE042238R2 Panel

Main Applications & Deployment Sites

Core Application: Local operator HMI for ABB System 800xA / AC 800M DCS, used for on‑site process monitoring and manual operation in process‑industry plants.

1. Thermal & Hydro Power Plants Local operator panels for boiler, turbine and auxiliary systems; local monitoring and operation of fans, pumps, water‑steam‑cycle process in power‑plant control cabinets.
2. Oil & Gas, Refineries & Petrochemical Plants Local control stations for process units, on‑site monitoring for reactors, distillation columns, pipeline process control.
3. Cement, Pulp & Paper, Metallurgy Heavy‑Industry Paper‑machine local HMI, kiln and mill‑drive operation panels for continuous production lines.
4. Offshore Oil‑Gas Platforms Marine‑qualified variant for offshore‑platform local operator interface, meets marine classification‑society requirements.
5. Water‑supply & Waste‑water Treatment Plants Local operator panels for large‑scale water‑treatment DCS systems.
6. Chemical & Pharmaceutical Plants Local control for continuous and batch‑process production lines.

ABB PP846A 3BSE042238R2 Panel

Key distinction summary for reference:

• PP846A: Panel 800 HMI operator touch panel, human‑machine interface for DCS.
• PM‑series (AC800M): DCS main CPU controller, execute real‑time control logic.
• DSAI130A: S800 analog‑input I/O board, collect field sensor signals.
• REM620 / REF610: Protection relays for motor and feeder fault protection.
• UFC911B101: Medium‑voltage‑drive main‑control CPU board.
• UNITROL 1020: Generator excitation AVR regulator.

ABB PP846A 3BSE042238R2 Panel
