Honeywell 51403224-200 LCNP PWA Bracket / Printed Wiring Assembly Bracket for Measurex DCS System
- Warranty： 365 days
- Quality: Original module
- Condition： New / Used
- Warehouse: Spot
- Delivery time: Shipped in 3 days after payment
- Mailbox：plcvarious@foxmail.com
Introduction
Main Functions
- Mechanical Mounting & Vibration Suppression It acts as the carrier bracket to securely hold the LCNP circuit board into the DCS rack slot. It provides mechanical reinforcement, absorbs vibration and shock in factory environments, preventing loose connection of the LCNP main board caused by equipment vibration.More products: www.plcva.com
- Backplane Signal Routing & Electrical Interface The integrated connector assembly on this bracket realizes the electrical interface between the LCNP main PCB and the rack backplane. It transmits LCN (Local Control Network) communication signals, power supply and diagnostic signals between the LCNP processor and other modules in the TDC/TPS rack.
- LCNP Board Protection & Heat Dissipation Aiding The bracket structure forms a protective housing for the LCNP printed wiring assembly, shielding the core circuit board from dust and mechanical collision. Its metal frame also assists passive heat dissipation for the LCNP processor module during continuous operation.plcva.com
- Module Positioning & Anti-misplugging Built-in positioning keys and locking mechanism ensure correct slot installation of LCNP board, preventing wrong insertion and reversed assembly which may cause hardware burnout. The locking structure keeps stable contact between gold fingers and backplane connectors for long-term running.
- Support for Module Hot-swap & Maintenance With standard extraction/locking handles, it supports convenient pull-out and replacement of the entire LCNP assembly bracket unit during maintenance, simplifying on-site spare part replacement for the legacy DCS rack.
- System Status Indicator Integration The bracket reserves mounting space for LED status indicators of the LCNP module, displaying power status, network link, run/fault alarms for field maintenance personnel to quickly judge module health.plcva.com
Honeywell 51403224-200 LCNP PWA Bracket / Printed Wiring Assembly Bracket for Measurex DCS System
Honeywell 51403224-200 LCNP PWA Bracket / Printed Wiring Assembly Bracket for Measurex DCS System
Applications & Purpose
The 51403224-200 is exclusively used as the LCNP PWA bracket for Honeywell Measurex / TDC300 / TPS legacy distributed control systems. Typical applications:
- Paper mill web measurement & quality control (core Measurex application scenario)
- Petrochemical and chemical plant TDC300 DCS control racks
- Power plant legacy process monitoring & control systems
- Pulp & paper industry online thickness, moisture and basis weight measurement control systems
- Existing factory DCS spare replacement for LCNP processor assembly
Notes: Honeywell 51403224-200 is End-of-Life (EOL). It is not a CPU, I/O or communication chip board, it is the complete bracket assembly that carries the LCNP printed circuit board. It is only available as spare replacement part for old installed Honeywell Measurex and TDC300/TPS DCS systems.
