Introduction
1.Core Functions
The NPort 5610-16 is an industrial serial-to-Ethernet gateway, converting 16-channel RS-232 serial signals into Ethernet TCP/IP network data, enabling remote access to serial devices over LAN.www.plcva.com
- 16-channel RS232 ↔ Ethernet conversion 16 independent RS-232 ports, each channel can communicate separately. It transparently transfers serial data over TCP/IP network.
- Multiple operating modes
- Real COM mode: Create virtual COM ports on host PC; PC software access remote serial devices just like local physical COM ports.
- TCP Server / TCP Client / UDP mode: Direct socket communication for custom SCADA or host applications.
- Wide baud rate range Baud rate: 50 bps ~ 921.6 kbps. Support hardware flow control (RTS/CTS) and software flow control (XON/XOFF).
- Web, Telnet and Windows utility configuration Configure network parameters, serial port settings and operation modes via web browser, Telnet or MOXA NPort Administrator software.
- Built-in network and serial diagnostics System self-diagnosis, port status LED indicators, event log, watchdog timer. Automatically reboot when system crash occurs.
- IP security & access control Access permission filtering, password protection for web configuration to prevent unauthorized modification.
- Power and hardware design Single DC power input 12–48 VDC. 19-inch rack-mount metal housing.
MOXA NPort 5610-16 Serial Device Server
2. Applications & Purpose
Core Purpose
It turns 16 local RS-232 serial instruments into network-connected devices. Operators and SCADA hosts can access these serial devices remotely via Ethernet, without running long serial copper cables. It solves the limitation of short transmission distance of traditional RS232.www.plcva.com
Typical Application Fields
- Factory automation: PLC, barcode readers, weighing instruments, serial printers
- Power and substation: RTU, meters, protection equipment with RS232 interface
- Building automation: HVAC controllers
- Logistics & warehouse: Serial scanning equipment
- SCADA & data acquisition systems
Working Flow
Field RS232 serial instruments → 16 DB9 serial ports of NPort 5610-16 → Convert serial data into TCP/IP packets → Ethernet network → Remote PC / SCADA server; PC uses virtual COM or TCP socket to read/write serial device data.www.plcva.com
MOXA NPort 5610-16 Serial Device Server
3. Key Specifications
- Serial ports: 16 × RS-232 DB9 ports
- Network interface: 1 × 10/100 Mbps Ethernet RJ45 port
- Serial standards: RS-232 only
- Baud rate: 50 bps ~ 921.6 kbps
- Operation modes: Real COM, TCP Server, TCP Client, UDP
- Mounting: 19-inch rack mount
- Power supply: 12 ~ 48 VDC
- Operating temperature: 0 ℃ ~ +55 ℃ (standard version)
- Supported OS: Windows, Linux for virtual COM driver
- Enclosure: Metal casing
Important distinction: NPort5610-16: RS232 only NPort5630-16: RS422/485 only NPort5650-16: RS232/422/485 multi-function version
This high-density rack-mount serial server is widely used when a large number of RS232 serial devices need to be networked in control room.
