GTR is a dedicated gear reduction motor series by NISSEI of Japan.
The model of the packaging box in the picture: G3F22N50
Model breakdown explanation:
G3: G3 series parallel-axis helical gear reduction motor (0.1 – 2.2 kW universal model)
F: Flange vertical installation (the right flange output model in the picture); L represents floor-mounted horizontal type; K is small flange
22: Base frame specification, suitable for 0.2 kW (200W) three-phase motor
N50: Reduction ratio 1:50
The suffix CM020TVGT: with electromagnetic brake, three-phase 200V standard voltage version
The three models in the picture correspond to three installation forms:
Left: G3L floor-mounted horizontal parallel-axis
Middle: G3K small flange
Right: G3F large flange vertical (the same as the packaging box G3F22N50)
II. Core product application

1. Basic function
   Integrating induction motor + helical gear reducer, reducing output speed and amplifying output torque, replacing ordinary motor + external reducer, with an integrated structure that is small in size, low in noise, and maintenance-free.
2. Mainstream industrial application scenarios
   Conveyor belt line
   Pneumatic conveyor, roller conveyor, sorting and transplanting, lifting platform, precise positioning stop for the braking model.
   Packaging machinery
   Vertical packaging machine, sealing machine, labeling machine, bottle sorting machine, paper box folding mechanism, low-speed large-torque driving for feeding, film winding.
   Automated assembly equipment
   Electronic conveyor line fixtures, screw machine, small rotating worktable, material flipping mechanism, suitable for braking models with frequent start-stop.
   Plastic / light industry machinery
   Small extrusion auxiliary machine, mixing and stirring, winding and unwinding equipment, stable driving of sheet material winding.
   Warehouse and logistics equipment
   Small lifting escalator, AGV auxiliary drive, shelf extension mechanism.
3. This 0.2kW / speed ratio 50 model is applicable to working conditions
   Output low speed, medium large torque, suitable for light-load continuous operation, and positions requiring precise braking;
   The electromagnetic brake model can stop without slipping, used for mechanisms with positioning requirements;
   Protection standard IP44 / optional IP65 waterproof model, available in workshop dust and mild humid environment.
   III. Core features
   Helical gear transmission, low operating noise, high transmission efficiency;
   Motor integrated compact design, smaller installation space;
   Power coverage 15W – 2.2kW, multiple reduction ratios 5 – 1800 available for selection;
   Optional electromagnetic brake, frequency conversion dedicated, waterproof IP65, clutch braking composite model;
   Multiple installation methods (floor-mounted / flange / double-axis output) suitable for different equipment structures.
