Main Functions

Hardware interface conversion: Converts Syntec controller M3 communication port to physical interface for connecting external handheld manual pulse generator(MPG / hand‑hold box).
Power supply output: Supplies stabilized operating power for the connected handheld MPG unit.

SYNTEC F31‑FC‑HHB‑M3‑PWR Hand‑Held Box Adapter Power Module

SRI high‑speed communication: Transmits manual jog pulse signals, switch & button signals between handheld box and Syntec CNC/automation controller via Syntec Remote Interface(SRI) bus.
Signal isolation & protection: Provides short‑circuit and over‑current protection for hand‑box peripheral circuit, stabilizes signal transmission in industrial cabinet environment.plcva.com
Hot‑plug compatible: Works with FC‑series distributed modular I/O system; system auto‑scans peripheral hand‑box device after power‑on without extra complex configuration.

SYNTEC F31‑FC‑HHB‑M3‑PWR Hand‑Held Box Adapter Power Module

Machine‑tool manual operation: Connect external handheld MPG hand‑box for manual jogging, axis fine‑tuning, tool setting on Syntec CNC machine tools (milling, lathe, grinding machine).
Robot / machine‑tending system: Applied for CNC‑robot loading‑unloading integration; realizes manual teaching & jog control for machine‑tool robotic arm peripherals.
Automation equipment: Used with Syntec FC‑series modular controllers for custom automation machinery, providing portable manual operation interface.plcva.com
Cabinet‑side expansion: Installed inside electrical control cabinet, acts as intermediate adapter module between main controller and remote handheld operating unit.
