ABB REF542PLUS (Order No.:1VCR007346, SUE3000), White Human‑Machine Interface Unit (New Model)
- Warranty： 365 days
- Quality: Original module
- Condition： New / Used
- Warehouse: Spot
- Delivery time: Shipped in 3 days after payment
- Mailbox：plcvarious@foxmail.com
Introduction
Main Functions
- Local human‑machine interaction: LCD display with membrane keypad for on‑site switchgear operation, including circuit‑breaker open/close, reset and alarm acknowledgement, commissioning without external laptop.
- Power‑system data & status visualization: Display single‑line diagram of primary system, three‑phase voltage, current, power, frequency and other measured values; show device operating status, interlock status and hardware faults.
ABB REF542PLUS
- Protection parameter configuration: Password‑protected access to view and modify protection settings, logic parameters, CT/PT ratios and parameter‑set switching; multi‑language support.
- Alarm, event & disturbance‑record review: Access SOE sequence‑of‑event logs, alarm lists and fault disturbance records for on‑site fault analysis and maintenance.
- Status LED indication: Front‑panel LEDs for ready, alarm, fault and interlock status to visualize real‑time condition of protection unit.
- Bus communication: Galvanically‑isolated RS485 communication with REF542PLUS main protection unit for data acquisition and command transmission; self‑powered for door‑mount separated installation.
- Local/remote mode selection: Toggle between local and remote control modes with operation interlock for switchgear safety.
Main Applications
This unit is the dedicated standalone HMI (SUE3000) for ABB REF542PLUS multifunction feeder protection and control device.
‑ Mounted on cabinet doors of 6‑35kV medium‑voltage switchgears. Widely applied in power substations, industrial power distribution rooms, industrial MV power‑distribution systems, GIS gas‑insulated switchgears and AIS air‑insulated switchgears.
‑ Used for local monitoring, parameter setting and equipment operation for feeder, transformer and motor protection bays. Provides full local maintenance capability when SCADA remote communication fails.
‑ Critical spare‑part for medium‑voltage relay‑protection systems for replacement of defective HMI panels of REF542PLUS protection terminals.
