Core Functions

High‑performance embedded main computing unit: Executes real‑time control algorithms, data processing and system management for VME‑chassis‑based systems. Equipped with up to 2 GB DDR2 SDRAM, CompactFlash non‑volatile storage and 32 KB NVRAM for persistent parameter storage upon power loss.
VMEbus master‑slave interface with PCI‑to‑VME bridge: Operates as VME bus master to initiate backplane data transfers; also supports slave mode for multi‑CPU system cooperation. The transparent PCI‑VME bridge converts signals between local PCI bus and VME backplane for inter‑board communication inside the rack.More products: www.plcva.com

GE Intelligent Platforms V7768‑320000 6U VMEbus Single‑Board Computer

Rich multi‑port onboard I/O resources: Provides dual Gigabit Ethernet, dual serial UART ports, four USB 2.0, dual SATA interfaces, PS/2 keyboard/mouse and SVGA video output. Supports direct connection to HMI, sensors, storage devices and upper‑level host systems.
PMC mezzanine expansion capability: The PCI‑X PMC slot accepts optional PMC daughter‑cards to add custom interfaces such as additional field‑bus, analog acquisition or motion‑control channels without changing the main SBC hardware.
Rugged system supervision & fault recovery: Features hardware watchdog timer for automatic system reset on software crash; on‑board temperature and voltage monitoring. Passive cooling design eliminates fan‑dependent failure points for harsh operating environments.
Real‑time operating‑system support: Optimized for industry‑leading real‑time OS, delivering deterministic response for time‑critical control and data‑acquisition tasks.plcva.com

GE Intelligent Platforms V7768‑320000 6U VMEbus Single‑Board Computer

V7768‑320000 serves as the primary CPU controller for legacy VME‑based mission‑critical systems across multiple industries.

GE Intelligent Platforms V7768‑320000 6U VMEbus Single‑Board Computer

Power generation turbine control: Deployed in GE Mark series turbine control racks for gas‑turbine / steam‑turbine governing, protection and data acquisition in power plants.
Defense & aerospace ground‑test systems: Used in hardware‑in‑the‑loop(HIL) simulation, radar pre‑processing, avionics test benches and military vehicle embedded computing.
Industrial process automation: Acts as main controller for heavy‑duty industrial control, nuclear‑facility monitoring and large‑scale test‑measurement equipment.
Marine & railway transportation: Embedded control for shipboard automation and railway signal processing systems, resisting vibration and wide temperature fluctuations.
Legacy VME system maintenance & retrofit: OEM spare replacement unit for existing VME chassis installations. It functions as drop‑in replacement for older‑generation VME SBCs, extending system service life without full redesign of the VME control rack.
