Yokogawa EC401‑10 Communication Module

Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mailbox：plcvarious@foxmail.com

+086 18205988494

Introduction

Main Functions

ESB Bus Master Communication Coupling It is the dedicated master interface module for ESB high‑speed backplane bus. Installed on Field Control Unit (FCU/AFV series), it establishes high‑speed deterministic communication between the main DCS controller and remote Node Units (NUs) with FIO/N‑IO I/O racks.
High‑speed Deterministic Data Transmission Communication speed reaches 128 Mbps, maximum transmission distance 10 meters. Supports connection of up to 9 node units. It cyclically transmits field acquisition data from remote I/O to FCU, and distributes control output commands from FCU down to field I/O modules.
Redundancy‑supported Architecture Supports dual‑module hot‑standby redundant deployment. Automatic fail‑over is triggered upon single‑module fault, maintaining continuous bus communication without process interruption for high‑reliability production sites.
Hot‑swap & Backplane Integration Rack‑mount design for FCU chassis, supports hot‑plug replacement under running system. Powered by DCS backplane, typical current consumption 0.5A, no extra external power required.
Hardware Self‑diagnosis & Status Indication Front‑panel LED indicators display module running status, bus link condition and fault alarms. It detects communication link breakdown, node unit failure and module hardware anomaly, and reports fault information to DCS system for maintenance troubleshooting.plcva.com

Note: EC401‑10 cannot work independently. It must be matched with Yokogawa AFV‑series FCU controllers and ESB‑bus Node Units. Some hardware revisions belong to legacy spare stock parts.

Yokogawa EC401‑10 Communication Module

Applications

This ESB bus coupler module is a core communication spare hardware for Yokogawa CENTUM DCS distributed control system:

Petrochemical & chemical industry: Expand distributed remote FIO I/O racks for reactor, distillation unit and process loop control.
Thermal power plants: Realize data interaction between field control stations and remote I/O nodes for boiler and turbine auxiliary control system.
Pulp‑paper, metallurgy and large water‑waste‑water projects: Build distributed I/O architecture for large‑scale continuous‑process production.
Industrial maintenance & retrofit: Replacement spare for faulty EC401‑10 module on existing CENTUM CS3000 / VP DCS systems, to recover ESB‑bus communication between FCU and remote I/O node racks.
