1.Core Functions

1. High-Precision Weighing Signal Acquisition & Conversion Receives millivolt analog signals from strain gauge load cells, equipped with high-resolution AD converter to convert raw signals into standard weight readings. Supports automatic zero tracking, tare function and manual zero reset to eliminate dead weight interference of hoppers and conveyors.
2. Multi-Stage Quantitative Batching Control (Core Process Function) Built-in 3-stage feeding logic: fast feed, fine feed and stop feed for precise quantitative filling & batching. Target weight and advance drop compensation value are freely configurable to minimize overfilling or underfeeding errors.
3. Multi-Channel Relay Digital Output & Alarm Multiple relay contact outputs configurable for over-weight alarm, under-weight alarm, batch completion signal and high/low material level interlock; directly drive solenoid valves, contactors and audible & visual alarms.
4. Industrial Data Communication & Upload Standard RS485 port with Modbus RTU protocol compatible. Connectable to PLC, HMI and industrial PC to upload real-time weight data and batch status for plant-wide automatic linkage.
5. Multi-Point Calibration & Parameter Memory 2-point / multi-point weight calibration with test weights; all calibration data and batching formulas are permanently stored after power-off. Supports unit switching (kg, ton, gram) and adjustable division value & digital filter strength for dusty or vibrating workshops.
6. Anti-Vibration Digital Filtering Multi-level digital filtering algorithm optimized for vibrating silos and moving conveyor scales to eliminate weight value flickering and maintain stable dosing accuracy.
7. External IO Trigger Terminals Compatible with external foot switches, start pushbuttons and level sensors to trigger automatic cyclic batching process for assembly lines.

2. Main Industrial Applications

1. Powder & Granule Quantitative Batching Lines Automatic batching scales for chemical powder, plastic pellets, grain & feed, building sand aggregate; precise weighing & feeding for multi-ingredient mixing production lines.
2. Packaging & Filling Machinery Food pouch filling, daily chemical liquid filling and hardware parts quantitative packaging; auto stop upon target weight to guarantee standard package weight.
3. Silo Material Level Monitoring Weight monitoring for storage tanks, mixing reactors and feed hoppers; high/low weight alarms to prevent material overflow or production interruption due to material shortage.
4. Assembly Line Checkweigher Sorting Finished product weight inspection on production lines; auto rejection for over/underweight goods, widely used in food, pharmaceutical and electronic product quality inspection.
5. Metallurgy & Construction Material Weighing Steel weighing, cement aggregate proportioning and asphalt mixing plant quantitative control; stable performance under heavy dust and strong vibration working conditions.
6. Automated Complete Equipment Supporting Matched with PLC control cabinets, integrated into filling all-in-one machines, mixing batching units and automatic weighing assembly lines for weight collection and logic control.
7. Warehouse & Logistics Weighing Supporting indicator for bench scales, barrel scales and forklift scales; real-time weight data upload to warehouse management system.
