Main Functions

Closed‑loop stepper motor drive control: Drives AZ‑series αSTEP closed‑loop stepper motors with built‑in battery‑free absolute encoder. Executes position, velocity and torque closed‑loop control, eliminates step‑loss phenomenon of traditional open‑loop stepper systems.
EtherCAT fieldbus communication: Dual RJ45 EtherCAT ports support daisy‑chain multi‑axis networking, complies with CiA402 drive profile and IEC 61800‑7 standard. Supports DC‑mode synchronous cycle down to 0.25 ms for high‑precision multi‑axis synchronized motion control.
Multiple motion operation modes: Supports profile position mode(PP), profile velocity mode(PV), homing mode(HM), cyclic synchronous position(CSP), cyclic synchronous velocity(CSV). It implements positioning, speed regulation and origin‑return functions for automated equipment.
Rich digital I/O interface: 6‑point photocoupler control inputs, 6‑point open‑collector control outputs, pulse input/output channels, power‑off monitor signal output. Realizes hardware interlock, trigger signal and status feedback with host PLC/controller.More products: www.plcva.com

Oriental Motor AZD‑KED

Battery‑free absolute position system: Retains absolute position value without backup battery. Directly reads motor absolute position upon power‑on, no homing procedure required after power‑up restart.plcva.com
Integrated multi‑layer protection: Built‑in over‑current, over‑voltage, over‑heat, motor short‑circuit and encoder fault protection. Triggers alarm output and stops drive output when abnormal conditions occur.
Parameter configuration and diagnosis: Supports MEXE02 configuration software for parameter tuning, waveform monitoring, alarm history reading and fault diagnosis. LED indicators display operation status and fault codes for on‑site troubleshooting.plcva.com
Safe power‑off monitoring function: Dedicated power‑shut‑down input and monitoring output channels, satisfying safety‑related motion control application requirements.

Oriental Motor AZD‑KED

Matched motors: Oriental Motor AZ‑series αSTEP closed‑loop stepper motors (AZM series rotary motors, DGM/DGR linear actuators).
Upper‑level controllers: EtherCAT‑based PLC, motion controllers and industrial automation hosts.
Target industries: Semiconductor equipment, electronic assembly machines, packaging machinery, automated production lines, laser processing equipment, testing instruments and logistics automation facilities.
Purpose: Realize high‑accuracy, high‑response multi‑axis positioning control for automated machinery. Achieve power‑on absolute positioning without homing, improve motion‑control reliability and production‑line efficiency. Used as drive spare‑part for existing AZ‑series motion‑control installations.
